Support for Canon R6


AZstarman
 Share

Question

  • Answers 9
  • Created
  • Last Reply

Top Posters For This Question

Top Posters For This Question

Posted Images

9 answers to this question

Recommended Posts

  • 0

Hi all,

Guylain, I downloaded the pre-release v3.2.1.RC3 and installed it on Win 10 on my laptop.  I was able to connect to the R6, but when I started a single capture I got the following message on the log file.



18:56:02  Licensed to blanked out

18:56:02  BackyardEOS 3.2.1 RC3

18:56:22  Attempting to connect camera...

18:56:22  Canon drivers 'Canon\' initialized.

18:56:23  EOS-R6 CONNECTED!

18:56:24  Unable to set ImageQuality, current setting is assumed!

18:56:34  Imaging session started.

18:56:34  Unable to set ImageQuality, current setting is assumed!

18:56:35  Capture Error: General camera error.

18:56:35  Imaging session cancelled

18:56:35  ERROR 36107 : EDSDK.EdsSendCommand(cameraRef, 4, 65539)

18:56:36  Imaging session cancelled

18:56:36  Unable to set ImageQuality, current setting is assumed!

18:57:06  Unable to set LiveviewAutoFocusMode, current setting is assumed!

18:57:13  Unable to set ImageQuality, current setting is assumed!

18:57:27  Imaging session started.

18:57:27  Unable to set ImageQuality, current setting is assumed!

18:57:28  Capture Error: General camera error.

18:57:28  Imaging session cancelled

18:57:28  ERROR 36107 : EDSDK.EdsSendCommand(cameraRef, 4, 65539)

18:57:29  Imaging session cancelled

18:57:29  Unable to set ImageQuality, current setting is assumed!





Perhaps this will help you.



Glen

Link to comment
Share on other sites

  • 0

Not yet.  Please download the latest release 3.2.1 and try it.

It will not connect but you should be getting something like this displayed in the message center, send me those numbers; they will tell me your model is supported by the current SDK, and we'll take from there.

14:26:58  DEVICEINFO DESCRIPTION IS MTP USB Device
14:26:58  DEVICEINFO NUMBER IS 2971957769.
14:26:58  YOUR *REAL* MODEL NUMBER IS 2147484722(80000432)

Link to comment
Share on other sites

  • 0
On 10/27/2020 at 1:15 PM, AZstarman said:

Hi all,

Guylain, I downloaded the pre-release v3.2.1.RC3 and installed it on Win 10 on my laptop.  I was able to connect to the R6, but when I started a single capture I got the following message on the log file.



18:56:02  Licensed to blanked out

18:56:02  BackyardEOS 3.2.1 RC3

18:56:22  Attempting to connect camera...

18:56:22  Canon drivers 'Canon\' initialized.

18:56:23  EOS-R6 CONNECTED!

18:56:24  Unable to set ImageQuality, current setting is assumed!

18:56:34  Imaging session started.

18:56:34  Unable to set ImageQuality, current setting is assumed!

18:56:35  Capture Error: General camera error.

18:56:35  Imaging session cancelled

18:56:35  ERROR 36107 : EDSDK.EdsSendCommand(cameraRef, 4, 65539)

18:56:36  Imaging session cancelled

18:56:36  Unable to set ImageQuality, current setting is assumed!

18:57:06  Unable to set LiveviewAutoFocusMode, current setting is assumed!

18:57:13  Unable to set ImageQuality, current setting is assumed!

18:57:27  Imaging session started.

18:57:27  Unable to set ImageQuality, current setting is assumed!

18:57:28  Capture Error: General camera error.

18:57:28  Imaging session cancelled

18:57:28  ERROR 36107 : EDSDK.EdsSendCommand(cameraRef, 4, 65539)

18:57:29  Imaging session cancelled

18:57:29  Unable to set ImageQuality, current setting is assumed!





Perhaps this will help you.



Glen



According to this it is current SDK supports it since it is connected.

The R6 has a 'B' dial mode for BULB.  Make sure you set it to B when taking bulb images, I suspect it might not.





Link to comment
Share on other sites

  • 0

Hi All,

I have been able to use BYEOS v3.2.1.RC3 with my R6, using Bulb setting not Manual. However, using that mode my settings were not saved when closing the program down.  Thus, each time you open BYEOS you had to reset all of your settings for that session.  My friend who helps me with computer issues found a work around for that problem.  I will touch base with him and see if he can share the steps to do this with all of you.  I am sure he will share that, I could try and walk you thru it but I might miss something.  I will contact him today.



Godspeed,

Glen

Link to comment
Share on other sites

  • 0

@AZstarman and @admin, confirming that I also was able to connect my Canon R6 through the Bulb setting. So, that was one step forward.

Unfortunately, I am also experiencing the same problem of the application not retaining settings from the previous session.

Additionally, the application crashed last night during a session with an “This is embarrassing” error message.

Will attempt to get more info later.



Link to comment
Share on other sites

  • 0
4 minutes ago, patpesetti said:

@AZstarman and @admin, confirming that I also was able to connect my Canon R6 through the Bulb setting. So, that was one step forward.

Unfortunately, I am also experiencing the same problem of the application not retaining settings from the previous session.

Additionally, the application crashed last night during a session with an “This is embarrassing” error message.

Will attempt to get more info latter.





Send me the log file.
